Fino Plane Company
34730 Oakland
Farmington, MI  48335
248-471-6500

email:  fpc at mmca.com   (substitute @ for at)

N47815           Click on thumbnail for a full size picture
 April 8 Solar Eclipse-Foreflight Install Instructions         Foreflight Overlays (download)


N47815 was repainted on 2/24/2023.  These are the pictures of the newly repainted airplane




Picture of old interior, before complete redo by Ambience Interiors:  Cockpit:  Cabin (Middle Seats)   Rear Seats

1978 Piper Seneca II  PA-34-200T  SN 34-7870004
Continental 200T  SFRM/SFRM   (1800 TBO) - installed 1/29/2014, 5711.9 total hours
      Left:    Cont TSIO360-EB3B   S/N 1009404, installed 1/29/2014
      Right:  Cont LTSIO360-EB3B  S/N 1009579, installed 1/29/2014

Hartzell 2 Blade Prop   (2000 TBO) Prop OH 1/1/2014
      Left:    BHC-C2YF-2CKUF
      Right:  BHC-C2YF-2CLKUF

Equipment and Accessories:


AVIONICS:   Summary of versions and serial numbers

Garmin Package:


    GTN-750 Xi Nav/Com, sn5FR004657, System ID 343004DA82C92,   (installed 7/23/2021)  WITH GDL-69A , v 6.71,  pilots guide (Rev D) Rev C PilotWorkshopManual   Internal Configuration
    GTN-650 Xi   Nav/Com, sn 5FP004749, System ID: 343004D963162, v6.71,) (installed 7/20/2021)   pilots guide (Rev D)  Rev C  PilotWorkshopManual (restricted)
    GMA-35    Remote Audio, sn 1T6000193 (shows on GTN-750) (installed 4/30/2011), vers 4.20A
    GTX-33ES Mode S     Remote Transponder, sn 89130209 (shows on GTN-750) (installed 10/08/2015, replaced 7/26/16 w sn 89123516), vers 8.04
    GDL-88    ADS-B Pilots Guide, sn 22T004351 (installed 10/8/2015), version 3.42
    GDL-69A Sirius XM Weather and radio (installed 4/30/2011), sn 47764220, version 4.02.00,Aviator Pro, Data Radio ID:  VWQGT00D, Audio Radio ID:  BBDDT0CJ
    Sandia 340 Quatro Standby Artificial Horizon, Airspeed, Altimeter, Slip, part no: 306171-00, SAI 340, sn: 350, software rev 15.0    pilots guide   Installation   Operational Parameters
   Flightstream 210  sn 3RE002701 (installed 10/08/2015), version 2.90, MAC Address:  10-C6-FC-75-75-52



KCS-55A  HSI Indicator   manual
GI-106A    Indicator
WX-500 Stormscope (on GTN-750)

STEC-60-2 Autopilot with Alert and Preselect  and GPSS Steer
Insight TAS1000 Air Data Computer (installed 3/5/2015)     Operation Manual  Configuration Settings  STC  Installation  Brochure
Electric Trim
Altex ME406 ELT (installed 12/1/2013)
Mountain High O2D2 Pulse Oxygen System With Al 682 (24 cu ft, 8 #, 4.4" dia x 27.6" long), 15.7 hrs at 18,000 ft)
Whelen OR6501G/R LED Nav lights (AC-20-41A and STC), installed 9/30/2016
Stratus Power, USB Ports (TSO'd), P/N 153010-000029, sn 055455   Installation
JPI 960 Engine Analyzer (installed 7/11/2019) sn 9084 K Factors: 29.8/29.8  now 29.46/29.46 Pilots Guide    Installation Manual    Panel Cutout    RDU Dimensions  Serial Numbers
   Addendum C to POH  EDM Configurator  EDM Configurator Doc   Operational Settings   Limits  Probes:  CHT:Bayonet Kit:  FAA TSO-C4 3/AS8005
Precise Flight Pulselite system  Model 1200/2405-2A  STC SA4005NM  Documentation
R.M.D. Lighted Wing TIps (RMD-00150-PS, STC SA1401NW), now Knots-2-U

NEW ICAO FLIGHT PLAN DESIGNATORS (as of 10/21/2018)
    ICAO Equipment:    B,G, S
            Old /G maps to new 'S'
            Add 'G' for GPSS
            WAAS with LPV adds 'B'
    ICAO Surveillance (transponder type):    B1, L, U2
          Mode S select 'S'
          GTX 33 ES with software version 8.04 means add 'LB1' instead of 'S' or 'H'
          GDL88 with GTX transponder with GS.  IF ADS-B out enabled on GTX, then add 'B1'  If ADS-B out enabled on GDL88 then add 'U2'
                (assuming ADS-B out enabled on GTX
           Add U@ since ADS-B is also OUT enabled
    Wake Turbulence:    Light
    ICAO PBN:            (leave blank)


CIRCUIT BREAKERS


OPTIONAL EQUIPMENT:

Certified for Flight Into Known Icing, Vortex Generators (BLR Aerospace 800-257-4847), RMD Tips with Recog Lites, 4 Light Strobe system, JPI 960 Graphical Engine Analyzer,  Precise Flight Pulselights, Bob Fields Door Seal, New Heavy main gear trunions, Boots replaced 2-13-89: Excellent condition-no patches, Whelan LED tail/strobe, Knot2U Wing Root Fairings, gap seals, other improvements

EXTERIOR:

Painted 2-24-2023 in three colors.   Matterhorn White BR11, Blue ESSS 197120, Oceanside blue ESSS 192023 by Custom Aviation, LLC, Jeff Cales, Ravenna, OhioPlanned new exterior paint (2021).  https://schemedesigners.com/Piper-SenecaII-Fino/   (design 5)
Tires:  55 psi mains, 30 psi nose
Hangar - KPTK, Hangar M-28   Floorplan   Left  Right  Center   Rt Engine

INTERIOR:

Complete, custom designed interior (5/1/2015) by Ambience Interiors with extra wide pilot/copilot seats with lumbar support.   Before Images    After Images

MODIFICATIONS/FORM 337's:
Form 337 Summary    Complete history of Form 337's from FAA as of
6/22/2021 (Airworthiness)
05-24-17 FAA Form 337 with FAA field approval changing max occupancy from 7 to 6

N47815 Summary Stats and AD Compliance.htm    Current Squawks

N47815 POH     Complete

Weight & Balance:   Excel file (2 tabs)         From POH: (CG Envelope      Loading Graph     Table (see tab POH)       Previous    Current)
Airworthiness Certificate      FAA Registration     FCC Station License      FCC Operator License   2023 Mchigan Registration

Log Books:   Airframe #3  Airframe #4   Left Engine   Right Engine   Left Propeller   Right Propeller   Recurring AD's   50 Hr Oil Analysis (Left Right)

Piper Service Manuals:  Parts (761-589)   Service (761-590)   Prop Deice Section (Goodrich 3E1150-10)

Supertow Manual  click here

SavvyAviation Articles:   FEVA2-Left   FEVA2-Right  ExhaustValveLapping   Ring Set Wash   Mikes OSH SlideDeck

MMCA Library of FAA Materiaclick here

Foscam Security Video:  Here

SPOT Tracker:

Frequently Ordered Items:
    Champion Oil Filter CH48108-1    Aircraft Spruce    $36.58 ea
    Michelin Airstop Tube 6.00-6, MFR Model # 092-500-0    Aircraft Spruce    $113,75 ea
    Condor Tire 6.00-6 8 Ply MFR Model 072-317-0            Aircraft Spruce        $169.00 ea
